TiltWatch

When you are serious about “This End Up”, a tilt indicator holds handlers accountable for keeping goods positioned correctly. SpotSee indicators typically reduce damage resulting from mishandling by 40 – 60%. With the addition of RFID technology, the TiltWatch® RFID alerts you if your product has been tipped and allows you to capture that data in your warehouse or shipping management systems.

Monitoring Range	Single plane
Tilt Threshold and Tolerance	85°, ±5° at 20°C / 68°F, 1 ATM
Operating Temperature and Humidity	-40°C to 60°C / -40°F to 140°F, 5-99% RH, non-condensing
RFID Type	ISO 18000-6 / EPC Gen 2 / Passive
Adhesive	2 mil high-tack acrylic
Adhesive Shelf Life	2 years
Composition	Rigid polystyrene housing with non-magnetic steel indicator
Dimensions	2.92 in x 2.37 in x 0.21 in / 74.27 mm x 60.31 mm x 5.29 mm
Weight	~14.17 g
Installation	Pressure-sensitive adhesive or holes to accommodate screws, nails or staples
